Six Cubic Meters(6m³) Concrete Truck
+86 185 0384 5123Order Phone
Overview:
Beiqi Futian Motor Company Limited is the most comprehensive and large-scale commercial vehicle enterprise in China, and it is also the best small agricultural truck manufacturer with the best reputation among consumers.
Concrete truck can automatically feed, measure, mix and discharge concrete mixture. Equipped with a powerful engine and 4 wheel steering, the operator can drive it to where it needs to go. It is very convenient for loading material, such as cement, aggregate and stone.
Features:
- Superior performance with the mixing tank.
- Simple operation and useful application.
- Unique space spiral blade can improve mixing efficiency.
- Convenient and efficient air pressure water supply cleans the part thoroughly.
- Multi-points control system enables the concrete truck operation to be easier, safer and more comfortable.
Technical:
| Type | 6m3 Mixing Transport Tank |
|---|---|
| Geometry capacity(m3) | 9.6 |
| Effective mixing capacity(m3) | 6 |
| Tank diameter(m) | 2.05 |
| Axis tilt | 14° |
| Dimensions(L×W×H) | 4935×2050×2365 mm |
| Installation size(mm) | 800×3900 |
| Speed(r/min) | 0-10 |
| Water box volume(L) | 350;300;400 |
| Type | Fu Tian 6m3 Concrete Truck |
|---|---|
| Power(HP) | 130 |
| Emission standard | National stage Ⅳ |
| Urea tank | Yes |
| Crossbeam(mm) | Double-250 |
| Gearbox | 5 |
| Rear axle(mm) | 1092 |
| Tyre size | 825R20 |
| Tread(mm) | 2250 |
| Wheelbase(mm) | 3600 |
| Braking | Air brake ABS |
| Fastest speed(km/h) | 80 |
| Dimensions(L×W×H) | 6825×2300×3450 mm |
